Effortlessly adjust the brightness of your lights with our 12/24 Volt LED Featuring advanced PWM stepless dimming and memory function, it provides smooth and flicker-free adjustments from 5% to 100%. The full aluminum decorative faceplate adds a touch of luxury, while the separate controls for on/off and rotary dimming make it extremely convenient.

With a maximum capacity of 15A and surge protection design, it works seamlessly with both DC12V and DC24V circuits, and can dim up to 180 watts of incandescent, halogen, or dimmable LED lighting.

Technical Specs

Working Voltage: DC12V-24V
Max Rated Current: 15 Amps at 12V system | 7.5 Amps at 24V system
Max Wattage: 180W
Dimmer Type: Low side PWM type
Compatible: LED lights, incandescent, halogen
Wiring: 4-wires (need wiring power negative and light fixture negative)
Switch Type: Push On Off, Rotary Knob Dimming
Switching Feedback: Faint ticking sound when on and off
Cutout: 1-5/8” x 1-5/8” x 7/8" (Depth)
Front Plate Size: 3-1/2" (W) x 2-1/2" (L)
Size: 2-1/2"(L) x 1-5/8”(W) x 3-1/2" (H)
